Commercial Specialty Lighting from New Horizon
New Horizon Lighting features a selection of specialty lighting fixtures that are perfect for specific commercial and industrial environments. From dock lights to vapor proof fixtures, along with a line of hazardous C1D2 options.
Specialty
NHL-STD SATELIS meets the lighting requirements for major roads and highways. Equipped with more powerful solar panels and higher capacity lithium battery packs to ensure battery run time, NHL-STD is the spec-grade LED solar lighting solution for most commercial applications.
New Horizon Lighting’s solar billboard lighting systems provide lighting for large and small billboards without the need for standard utility power. Billboards, entrance signs, building name signs and other similar items, oftentimes, are placed in locations with little or no access to the electrical grid. Connecting them to the grid involves investments of time and money, such as cabling, trenching, and permitting. New Horizon Lighting’s BROADWAY provides cost savings by eliminating the need to trench standard elec tri c wires for installation and providing no electric bill for the life of the system.
This versatile solar flood light has a separate solar panel to collect energy from the sun. The solar panel also contains a sensor which activates the light when it is sufficiently dark. This unit comes with a remote control so that you can select your desired mode, brightness and timer options. After a full charge, this solar light can be activated in increments of 10% brightness for a full 12 hours. If not fully charged, it has a built-in feature that adjusts to the maximum possible brightness for up to 12 hours. It can also be set on a timer mode for 3 hours, or 5 hours. There is also a Manual mode that allows the user to turn on the light and keep it on, for as long as desired. In this mode, the light will not turn off automatically during daylight hours and must be turned off manually.
These LED Explosion Proof Lights can provide general illumination in hazardous locations such as oil refineries, gasoline loading docks, distilleries, pumping stations, mines, vessels, paint manufacturing plants and other high humidity, high temperature, dusty locations.
HLX Specifications
- Housing: Copper Free diecast aluminum.
- Listing & Ratings: • NEMA 4X, IP66 • UL1598/UL1589A/UL844 • CSA C22.2 No. 137/No.250.0 Class I, Division 2, Groups A,B,C,D Class II, Division 1, Groups E,F,G Class II, Division 2, Groups E,F,G Class III.
- Finish: Heavy duty gray powder coat.
- Lens: Clear impact resistant lens.
- Mounting Options: Surface mounting and pendant installations.
- Wattage: From 20-200 Watts
- Driver: Mean Well Driver.
- Warranty: 5-Year Warranty from the date of purchase. The warranty is invalid in the case of improper installation, tampering, or removal of the Q.C. date label.
HLX1 Specifications
- Housing: Copper Free diecast aluminum.
- Listing & Ratings: • NEMA 4X, IP66 • UL1598/UL1589A/UL844 • CSA C22.2 No. 137/No.250.0 Class I, Division 1, Groups C,D Class I, Division 2, Groups A,B,C,D Class II, Division 1, Groups E,F,G Class II, Division 2, Groups E,F,G Class III.
- Finish: Heavy duty gray powder coat.
- Lens: Clear impact resistant lens.
- Mounting Options: Surface mounting and pendant installations.
- Wattage: From 20-200 Watts
- Driver: Mean Well Driver.
- Warranty: 5-Year Warranty from the date of purchase. The warranty is invalid in the case of improper installation, tampering, or removal of the Q.C. date label.
The NHL-HDCVT4 Class 1, Division 2 Hazardous Location 4' series wall, pendant and ceiling mount luminaire is available with clear or opal lenses and open door frame designed to replace HID lighting systems up to 400w MH or HPS. Typical lighting applications include retail centers, industrial parks, schools and universities, public transit and airports, office buildings and medical facilities. NSF certification meets the requirements for Food Processing Facilities. Mounting heights of 18 to 30 feet can be used based on light level and uniformity requirements.
New Horizon Lighting is proud to offer our LED Dock light! Suitable to replace any older HID or Incandescent dock light, and available in multiple lumen packages and custom colors. Two arms lengths also available to meet your mounting requirements.
